231
          Rolling Warehouse Ladders (12 to 16 Step)

          Finally an easy and safe solution for reaching products on high shelves. Each ladder is rated at
          350 pounds uniform capacity. Units feature a 58° climb angle and the EZ models features a 50°
          climb angle. The handrail height is 36" from the top step and around the top step a 4" toeboard
          is included. Each step is 24" wide by 7" deep. Choose either grip strut style or perforated style
          steps. Front wheels are 3" diameter. Side frame is constructed from welded square tubular steel
          and offers maximum strength. Unique design allows ladder to separate for shipping and storage.
          Welded steel construction with baked-in powder-coated toughness. Manufactured in compliance
          with OSHA 1910.29 and ANSI A14.7 standards.
          Optional safety gate sold separately to help keep children and unauthorized personnel off the
          ladder. Activating the caster floor lever will lift the gate into an upright position. Pushing the gate
          forward will disengage the casters from the floor and allow for safe access to the ladder.

                MODEL      NO. OF   TOP STEP   OVERALL   BASE SIZE  TOP STEP  WEIGHT                               INDUSTRIAL & COMMERCIAL LADDERS
               NUMBER       STEPS  HEIGHT  HEIGHT     (W x D)   DEPTH   (POUND)
           GRIP STRUT STEPS - 58°
           LAD-12-14-G       12     120"    156"    34¼" x 91 /16"  14"  391
                                                           5
           LAD-13-14-G       13     130"    166"    42¼" x 95 /16"  14"  441
                                                           9
           LAD-14-14-G       14     140"    176"   42¼" x 101 /8"  14"   466
                                                           7
           LAD-15-14-G       15     150"    186"     42¼" x 108"  14"    489
           LAD-16-14-G       16     160"    196"    42¼" x 115¼"  14"    522
           LAD-12-21-G       12     120"    156"    34¼" x 97½"  21"     414
           LAD-13-21-G       13     130"    166"   42¼" x 102 /16"  21"  457
                                                           9
           LAD-14-21-G       14     140"    176"   42¼" x 108 /8"  21"   482
                                                           7
           LAD-15-21-G       15     150"    186"     42¼" x 115"  21"    505
           LAD-16-21-G       16     160"    196"   42¼" x 122¼"  21"     527                       model LAD-16-21-G
           PERFORATED STEPS - 58°
           LAD-12-14-P       12     120"    156"    34¼" x 91 /16"  14"  388
                                                           5
           LAD-13-14-P       13     130"    166"    42¼" x 95 /16"  14"  472
                                                           9
           LAD-14-14-P       14     140"    176"   42¼" x 101 /8"  14"   478
                                                           7
           LAD-15-14-P       15     150"    186"     42¼" x 108"  14"    490
           LAD-16-14-P       16     160"    196"    42¼" x 115¼"  14"    507
           LAD-12-21-P       12     120"    156"    34¼" x 97½"  21"     402
           LAD-13-21-P       13     130"    166"   42¼" x 102 /16"  21"  453
                                                           9
           LAD-14-21-P       14     140"    176"   42¼" x 108 /8"  21"   478
                                                           7
           LAD-15-21-P       15     150"    186"     42¼" x 115"  21"    501       GRIP STRUT STEP
           LAD-16-21-P       16     160"    196"   42¼" x 122¼"  21"     552
           GRIP STRUT STEPS - 50°
           LAD-12-14-G-EZ    12     120"    156"   34¼" x 110 /8"  14"   434
                                                           7
           LAD-13-14-G-EZ    13     130"    166"   42¼" x 120 /8"  14"   453
                                                           7
           LAD-14-14-G-EZ    14     140"    176"   42¼" x 128 /16"  14"  502
                                                           1
           LAD-15-14-G-EZ    15     150"    186"   42¼" x 136 /16"  14"  505
                                                           5
           LAD-16-14-G-EZ    16     160"    196"  42¼" x 144 /16"  14"   527                    PERFORATED STEP
                                                          13
           LAD-12-21-G-EZ    12     120"    156"   34¼" x 121 /16"  21"  416
                                                           7
           LAD-13-21-G-EZ    13     130"    166"   42¼" x 127 /8"  21"   478
                                                           7
           LAD-14-21-G-EZ    14     140"    176"   42¼" x 135 /16"  21"  496
                                                           1
           LAD-15-21-G-EZ    15     150"    186"   42¼" x 143 /16"  21"  521
                                                           5
           LAD-16-21-G-EZ    16     160"    196"  42¼" x 151 /16"  21"   542
                                                          13
           PERFORATED STEPS - 50°
           LAD-12-14-P-EZ    12     120"    156"   34¼" x 110 /8"  14"   398
                                                           7
           LAD-13-14-P-EZ    13     130"    166"   42¼" x 120 /8"  14"   450
                                                           7
           LAD-14-14-P-EZ    14     140"    176"   42¼" x 128 /16"  14"  476
                                                           1
           LAD-15-14-P-EZ    15     150"    186"   42¼" x 136 /16"  14"  501
                                                           5
           LAD-16-14-P-EZ    16     160"    196"  42¼" x 144 /16"  14"   523
                                                          13
           LAD-12-21-P-EZ    12     120"    156"   34¼" x 121 /16"  21"  413
                                                           7
           LAD-13-21-P-EZ    13     130"    166"   42¼" x 127 /8"  21"   465
                                                           7
           LAD-14-21-P-EZ    14     140"    176"   42¼" x 135 /16"  21"  492
                                                           1
           LAD-15-21-P-EZ    15     150"    186"   42¼" x 143 /16"  21"  516
                                                           5
           LAD-16-21-P-EZ    16     160"    196"  42¼" x 151 /16"  21"   538
                                                          13
           OPTIONS
           LAD-GATE-58            FOOT ACTIVATED SAFETY GATE 58°          44
           LAD-GATE-50-EZ       FOOT ACTIVATED SAFETY GATE 50° -EZ        45
           LAD-TT-B                        TOOL TRAY                      14
                                                                                   model LAD-16-21-G shown
                                                                                   with LAD-GATE-58 option
