98 Achieve the extra reach you're looking for with our Double Scissor Lift Tables. These full featured electric
ERGONOMIC SOLUTIONS hydraulic double scissor lift tables are used by all types of manufacturing and warehouse facilities. Safety
Double Scissor Lift Tables
460V 3-PHASE STD, OPTIONS ON PG. 108

features include: electric toe guard to protect pinch points during lowering of the table, safety velocity fuse
to maintain platform height in the event of a hose or fitting failure, 24V AC push-button hand control,
maintenance prop, and upper travel limit switch to stop the table at maximum height reducing motor wear.
2 HP, 3-phase, 60 Hz totally enclosed motor standard, other voltage and phase available. 3000 psi hydraulic
component rating. See options on page 108 & 109. Survey sheet available on page 150.

LOWERED
PLATFORM
RAISED
UNIFORM
PLATFORM
VERTICAL
WEIGHT
TRAVEL TIME
TRAVEL
WIDTH
LENGTH
HEIGHT
(SEC)
HEIGHT
CAPACITY
11
1,000 lb.
1157
60" Model Number Format: EHLTD - (width)(length) - capacity - raised height (POUND)
48" - 72"
70"
34" - 48"
10"
60" 34" - 48" 48" - 72" 2,000 lb. 70" 10" 16 1250
60" 34" - 48" 48" - 72" 3,000 lb. 70" 10" 22 1343
60" 34" - 48" 48" - 72" 4,000 lb. 70" 10" 32 1436
60" 34" - 48" 48" - 72" 5,000 lb. 70" 10" 34 1529
72" 34" - 48" 64" - 88" 1,000 lb. 84" 12" 16 1576
72" 34" - 48" 64" - 88" 2,000 lb. 84" 12" 32 1669
72" 34" - 48" 64" - 88" 3,000 lb. 84" 12" 48 1762
72" 34" - 48" 64" - 88" 4,000 lb. 84" 12" 48 1855
72" 34" - 48" 64" - 88" 5,000 lb. 84" 12" 48 1948
TRAVEL TIME BASED ON 460V THREE-PHASE POWER
Portable Scissor Lift Tables 12V DC STD, OPTIONS ON PG. 108-109
Portable Scissor Lift Tables are designed to transport and elevate your heaviest loads. A heavy-duty 12V
DC power unit with deep cycle battery, an on-board battery charger and battery charge indicator gauge are
standard. Features 8" glass filled nylon casters (two swivel and two rigid), floor lock, and patented electric
pinch point guards. Push buttons to raise and lower lift, and the magnetic hand control on an 8 ft. cord
are standard. Key-operated ON/OFF control for better security is built into the power unit. Add 28½" to
platform length for the overall length. Survey sheet available on page 150.
Model Number Format: PST - (width)(length) - capacity - raised height
VERTICAL PLATFORM PLATFORM UNIFORM RAISED LOWERED TRAVEL TIME WEIGHT
TRAVEL WIDTH LENGTH CAPACITY HEIGHT HEIGHT (SEC) (POUND)
36" 24" - 48" 48" - 72" 1,000 lb. 46" 10" 9 1046
36" 24" - 48" 48" - 72" 2,000 lb. 46" 10" 14 1218
36" 24" - 48" 48" - 72" 3,000 lb. 46" 10" 20 1385
35" 36" - 48" 48" - 72" 4,000 lb. 47" 12" 28 1770
35" 36" - 48" 48" - 72" 5,000 lb. 47" 12" 31 1810
48" 24" - 48" 64" - 90" 1,000 lb. 58" 10" 14 1331
48" 24" - 48" 64" - 90" 2,000 lb. 58" 10" 20 1363
48" 24" - 48" 64" - 90" 3,000 lb. 58" 10" 28 1224
48" 36" - 48" 64" - 90" 4,000 lb. 60" 12" 38 1800
48" 36" - 48" 64" - 90" 5,000 lb. 60" 12" 38 2266
PORTABLE SCISSOR TABLE PORTABLE SCISSOR TABLE OPTIONS
SHOWN WITH PST-PTDS-E OPTION MODEL WEIGHT
NUMBER DESCRIPTION (POUND)
VCC-115-1 AC MOTOR (115V, 1 PHASE, 3/4 HP, 60 Hz MOTOR) W/HAND CONTROL 22
PST-AIR* RECIPROCATING AIR/OIL (FOOT TREADLE CONTROL (FRL REQ'D)*) --
PST-FP MANUAL FOOT PUMP OPTION --
PST-PTDS-E POWER TRACTION DRIVE SYSTEM, 24V DC (1-3,000 lb. capacity) 600
PST-PTDS POWER TRACTION DRIVE SYSTEM, 24V DC (4-5,000 lb. capacity) 231
*FILTER REGULATOR - LUBRICATOR REQUIRED TO OPERATE
Hydraulic Motorcycle Lift

Manual foot pump activated stationary lift. Ideal for casual and professional riders to work on their
motorcycles. Features a front tire cradle to hold wheels up to 6" wide. The hinged ramp measures 27½"
wide by 21½" long.

MODEL OVERALL SIZE BASE FRAME UNIFORM SERVICE WEIGHT
NUMBER (W x L) (W x L) CAPACITY RANGE (POUND)
MOTO-LIFT-1100� 35" x 108" 26¾" x 65" 1,100 lb. 7" to 32" 689
