          Economy Transporter / Tilter

          Move product between work stations. Tilt crates for easier access.  2½" lip holds units in place
          when tilted. Manual foot pump operation.  Tilts 23° in just 11 strokes.  Features a removable
          handle.  Rolls smoothly on two (2) swivel with brakes and two (2) rigid poly-on-steel 5" x 2"
          casters.  Baked-in powder-coated toughness.
             MODEL      PLATFORM     UNIFORM      LEVEL      MAXIMUM    WEIGHT                                     ERGONOMIC SOLUTIONS
             NUMBER     SIZE (W x L)  CAPACITY    HEIGHT      TILT     (POUND)
           ETT-254     40" x 42¼"    2,500 lb.     10"        23°        254


          Manual Tilt Master
          Lift, tilt, and transport crates, boxes, and pallets with an open bottom. Designed to give the user
          an ergonomically correct position to reach loads easily without the need for bending down or
          excessively reaching over. Forks can be tilted to 90°. Rolls smoothly on 6" x 2" polyurethane swivel
          casters with brake and foot protectors. Width between forks is 9½". The overall fork width is 22".
          The individual fork width is 6¼".
                                                                                   SKID ONLY
             MODEL     UNIFORM   VERTICAL   LOWERED    FORK    OVERALL  WEIGHT
            NUMBER     CAPACITY  LIFT HEIGHT  FORK HEIGHT  LENGTH  WIDTH  (POUND)
           TM-22-M �  2,200 lb.   11¼"        3½"      31½"     25¼"     413
                                                                                  NO PALLET

          Efficiency Master Tilt Tables     460V 3-PHASE STD, OPTIONS ON PG. 108
          The model EM1-200 tilts pallets, crates, boxes, or baskets 45° to facilitate easy container loading
          or unloading. Tables feature all welded steel construction for years of durability. Unique design
          minimizes pinch points to meet OSHA requirements. Units are equipped with an industrial
          quality, 56 frame 2 HP motor. This motor delivers best torque with minimal amperage draw for
          maximum life. Standard voltage is 460V 3 phase, other voltages available. A 24V push button
          hand control is standard.  Base includes 7½"W x 2½"H usable fork pockets on 30" centers for
          portability with forklift.  Survey sheet available on page 152.
          The model EM1-500 incorporates many of the same quality features found in the Series
          EM1-200, but features a full 90° of tilt. Unit is ideal for upending products in shipping and
          receiving operations. Standard with double acting cylinder for controlled tilt and return. Unit
          must be lagged to floor.

                MODEL       USABLE SIZE  UNIFORM  MAXIMUM   HORIZONTAL  WEIGHT
               NUMBER        (W x L)   CAPACITY     TILT      HEIGHT   (POUND)
           EM1-200-4250-2   42" x 50"  2,000 lb.    45°        24"      740
                                                                                          45° EFFICIENCY MASTER
           EM1-200-4848-2   48" x 48"  2,000 lb.    45°        24"      697           features a 12" high lip series EM1-200
           EM1-200-6050-2   60" x 50"  2,000 lb.    45°        24"      834
           EM1-200-4250-4   42" x 50"  4,000 lb.    45°        24"      780
           EM1-200-4848-4   48" x 48"  4,000 lb.    45°        24"      733
           EM1-200-6050-4   60" x 50"  4,000 lb.    45°        24"      894         Custom Finish
           EM1-200-4250-6   42" x 50"  6,000 lb.    45°        24"      822          Available
           EM1-200-4848-6   48" x 48"  6,000 lb.    45°        24"      832
           EM1-200-6050-6   60" x 50"  6,000 lb.    45°        24"      912
           EM1-500-4250-2   42" x 50"  2,000 lb.    90°        24"      849
           EM1-500-4848-2   48" x 48"  2,000 lb.    90°        24"      887
           EM1-500-6050-2   60" x 50"  2,000 lb.    90°        24"      1035
           EM1-500-4250-4   42" x 50"  4,000 lb.    90°        24"      870
           EM1-500-4848-4   48" x 48"  4,000 lb.    90°        24"      905
           EM1-500-6050-4   60" x 50"  4,000 lb.    90°        24"      1047
           EM1-500-4250-6   42" x 50"  6,000 lb.    90°        24"      865
           EM1-500-4848-6   48" x 48"  6,000 lb.    90°        24"      923
           EM1-500-6050-6   60" x 50"  6,000 lb.    90°        24"      1106
                                                                                      90° EFFICIENCY MASTER
          OPTIONAL FOOT CONTROL, model FC-2
                                                                                   features a 24" high lip series EM1-500
           EFFICIENCY MASTER TILT TABLE OPTIONS

             MODEL NUMBER                                DESCRIPTION
           EM1-300-APPB    *HAND HELD CONTROL AIR POWERED HYDRAULIC - ROTARY-PB-2, FOR 45° TILTERS
           EM1-300-APFC    *FOOT CONTROL AIR POWERED HYDRAULIC - ROTARY-FC-2, FOR 45° TILTERS
           EM1-300-APFT    *FOOT TREADLE AIR POWERED 2000# & 4000# ONLY - RECIPR, FOR 45° TILTERS
           EM1-600-APPB    *HAND HELD CONTROL AIR POWERED HYDRAULIC - ROTARY-PB-2, FOR 90° TILTERS
           EM1-600-APFC    *FOOT CONTROL AIR POWERED HYDRAULIC - ROTARY-FC-2, FOR 90° TILTERS
          *FILTER REGULATOR - LUBRICATOR REQUIRED TO OPERATE UNIT
